No. Name CN# Meaning
1 CN1A
CN3 Earth: connect to Ground
CN1 N_in: connect to N-line (208-230V AC input)
CN2 L_in: connect to L-line (208-230V AC input)
CN16 S: connect to indoor unit communication
2 HEAT1 CN17 connect to compressor heater, 208-230V AC when is ON
3 4-WAY CN60 connect to 4 way valve, 208-230V AC when is ON.
4 HEAT2 CN15 connect to chassis heater, 208-230V AC when is ON
5 AC-FAN CN25 connect to AC fan
6 PMV CN31 connect to Electric Expansion Valve
7 TESTPORT CN6 used for testing
8 TP T4 T3 CN21/CN22
connect to pipe temp. sensor T3, ambient temp. sensor T4, exhaust
temp. sensor TP
9 DC-FAN CN7 connect to DC fan
10 FAN_IPM IPM 501 IPM for DC fan
11
W CN28 connect to compressor
V CN29 0V AC (standby)
U CN30 10-200V AC (running)
12 COMP_IPM IPM 301 IPM for compressor
Note: This section is for reference only. Please take practicality as standard.
