 Outdoor Unit Disassembly 24 
Procedure Illustration
4) Remove the screws of the front panel
and then remove the front panel (7
screws) (see CJ_CA01_003).
5) Remove the screws of water collecting
cover and then remove the water
collecting cover (2 screws) (see CJ_
CA01_004).
CJ_CA01_003
CJ_CA01_004
Note: This section is for reference only. Actual unit appearance may vary.
Front Panel
Water Collecting Cover
