Midea MTA-76C(H)RN1 User Manual

MCAC-UTSM-201501 Midea R410A T3 Top-discharge Split Type Series 50Hz
14
Model
MHB-96HRN1
MHB-96CRN1
Type
High static pressure duct
Power supply
\
220-240V~, 1Ph, 50Hz
Cooling
Capacity (T1/T3)
Btu/h
95,600/80,500
95,600/80,500
W
28,000/23,600
28,000/23,600
Input (T1/T3)
W
9,600/11,550
9,600/11,550
EER (T1)
W/W
2.92
2.92
Heating
Capacity
Btu/h
105,000
\
W
31,000
\
Input
W
10,300
\
COP
W/W
3.01
\
Rated input (Whole units)
W
14,400
14,400
Rated current (Whole units)
A
23.7
23.7
Indoor air flow
m
3
/h
5,100
5,100
Indoor standard ESP (External static pressure)
Pa
196
196
Indoor noise level
dB(A)
61
61
Refrigerant type
\
R410A
R410A
Refrigerant control
\
Capillary
Fan
Type
\
Centrifugal fan
Centrifugal fan
Motor model (×Quantity)
\
YDK550-4X(×2)
YDK550-4X(×2)
Input (Hi/med/lo)
W
990/830/670
990/830/670
Capacitor
\
12μF/450V
12μF/450V
Speed (Hi/med/lo)
r/min
1,130/990/840
1,130/990/840
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф9.52
Ф9.52
No. of rows
\
4
4
Fin spacing
mm
1.5
1.5
Tube pitch(a)×row pitch(b)
mm
25.4×22
25.4×22
Length× height
mm
1,202×406.4
1,202×406.4
Number of circuits
\
14
14
Controller
\
R51/E
R51/CE
Refrigerant pipe (Liquid/ Gas)
mm
Ф9.52/Ф25
Ф9.52/Ф25
Drain pipe size
mm
Ф41
Ф41
Dimension (W×H×D)
mm
1,443×450×846
1,443×450×846
Packing (W×H×D)
mm
1,549×476×917
1,549×476×917
Net/Gross weight
kg
105/120
105/120
Notes:
1. Nominal cooling capacities are based on the following conditions:
T1: Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; T3: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 46°CDB; Equivalent refrigerant piping: 7.5m (horizontal).
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB; Equivalent refrigerant piping: 7.5m (horizontal).

Midea MTA-76C(H)RN1 Specifications

General

Brand	Midea
Model	MTA-76C(H)RN1
Category	Air Conditioner
Language	English
