Midea MTA-76C(H)RN1

Midea R410A T3 Top-discharge Split Type Series 50Hz MCAC-UTSM-201501
59
1. Specifications
Model
MOV-76HN1-C
MOV-76CN1-C
Power supply
\
380-415V~, 3Ph, 50Hz
Ambient temp in cooling
°C
17～52
17～52
Ambient temp in heating
°C
-7~24
/
Rated input (Whole units)
W
11,700
11,700
Rated current (Whole units)
A
19.3
19.3
Noise level
dB(A)
65
65
Compressor
Type ×Qty.
\
Scroll ×1
Scroll ×1
Brand
\
Copeland
Copeland
Model
\
ZP90KCE-TFD-522
ZP90KCE-TFD-522
Capacity
W
21,900
21,900
Input
W
6,950
6,950
Rated current
A
16.5
16.5
Locked rotor Amp
A
95
95
Refrigerant oil
ml
2,513
2,513
Refrigerant
Type/Charge
\
R410A/5,400g
R410A/5,400g
Fan
Type ×Qty.
\
Axial fan ×2
Axial fan ×2
Motor model
\
YDK210-6A
YDK210-6A
Motor input
\
Hi: 284; Lo: 202
Hi: 284; Lo: 202
Capacitor
\
10μF/450V
10μF/450V
Motor speed
rpm
Hi: 920/930; Med: 650/710 (4/3 fan blades)
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7.94
Ф7.94
No. of rows
\
2
2
Fin space
mm
1.4
1.4
Tube pitch(a)×row pitch(b)
mm
22×19.05
22×19.05
Coil (W×H)
mm
2,177×880
2,177×880
Number of circuits
\
9
9
Refrigerant
pipe
Liquid side/ Gas side
mm
Φ9.52/Φ22
Φ9.52/Φ22
Max. pipe length
m
50
50
Max. difference in level
m
30(Outdoor unit down), 25(Outdoor unit up)
Connection
wire
Power wire (Indoor unit)
\
3×2.5mm
2
3×2.5mm
2
Power wire(Outdoor unit)
\
5×6.0mm
2
5×6.0mm
2
Power wire(Double outdoor
units, as power-main)
\
5×10.0mm
2
5×10.0mm
2
Signal wire
\
4×1.0mm
2
2×1.0mm
2
Dimension (W×H×D)
mm
1,260×908×700
1,260×908×700
Packing (W×H×D)
mm
1,320×1,060×730
1,320×1,060×730
Net/ Gross weight
kg
174/193
171/190
Notes:
Nominal cooling capacities are based on the following conditions: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 35°CDB; Nominal heating capacities are based on the following conditions: Indoor temp: 20°CDB;
Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. piping: 7.5m (horizontal).
