2. Specifications
Model
MFA-76HRN1
MFA-76CRN1
Power supply
\
220~240V-1Ph-50Hz
Cooling
Capacity (T1/T3)
Btu/h
75,100/64,800
75,100/64,800
W
22,000/19,000
22,000/19,000
Input power (T1/T3)
W
7,500/8,980
7,500/8,980
EER (T1)
W/W
2.93
2.93
Heating
Capacity
Btu/h
85,000
\
W
25,000
\
Input power
W
8,300
\
COP
W/W
3.01
\
Rated input (Whole units)
W
11,700
11,700
Rated current (Whole units)
A
19.3
19.3
Indoor air flow
m
3
/h
4,250
4,250
Indoor noise level
dB(A)
58
58
Refrigerant type
\
R410A
Refrigerant control
\
Capillary
Fan
Type
\
Centrifugal fan
Motor model
\
YSK300-6
YSK300-6
Motor input(hi/med/lo)
W
600/500/437
600/500/437
Capacitor
\
25μF/450V
25μF/450V
Motor speed(hi/med/lo)
rpm
870/760/670
870/760/670
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф9.52
Ф9.52
No. of rows
\
2
2
Tube pitch(a)×row pitch(b)
mm
25.4×44
25.4×44
Fin spacing
mm
1.6
1.6
Coil(W×H)
mm
982×711.2
982×711.2
Number of circuits
\
14
14
Controller
\
R51/E
R51/CE
Refrigerant pipe (Liquid/ Gas)
mm
Ф9.52/Ф22
Ф9.52/Ф22
Drain pipe size
mm
Ф41
Ф41
Dimension (W×H×D)
mm
1,200×1,860×518
Packing (W×H×D)
mm
1,362×2,050×582
Net/Gross weight
kg
158/174
158/174
Notes:
1. Nominal cooling capacities are based on the following conditions:
T1: Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; T3: Indoor temp: 27°CDB, 19°CWB;
Outdoor temp: 46°CDB; Equivalent refrigerant piping: 7.5m (horizontal).
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB; Equivalent refrigerant piping: 7.5m
(horizontal).
