Midea R410A T3 Top-discharge Split Type Series 50Hz MCAC-UTSM-201501
73
3. Installation of Floor-standing Type Indoor Units
As the following picture, when install the indoor unit, select the enough solid and level site
with enough space for installation and maintance.
For anti-fall down, following the picture (unit: mm) fix the feet on the floor after select
aproper place for installation, since the height of the unit casing is very high. The right and
left sides as weel as rear can be fixed, it is necessary to select the unit fixed measure as per
to the actual installing ambient.
Notes:
It is be ware of the foot screw, which may be hurt for the passby people, make sure enough securit
of that, prevent accident occure.
Before electric connection, uncover the screw-cap in the air intake panel, and then lossen
the screws.
Take off the air intake panel, ensure which place secure enough will not make risk to the
other people.
