Midea MTA-76C(H)RN1 User Manual

MCAC-UTSM-201501 Midea R410A T3 Top-discharge Split Type Series 50Hz
42
Model
MFAT-120CRN1
Power supply
\
220~240V-1Ph-50Hz
Cooling
Capacity (T1/T3)
Btu/h
121,000/110,900
W
35,000/32,500
Input power (T1/T3)
W
13,000/15,500
EER (T1)
W/W
2.69
Heating
Capacity
Btu/h
\
W
\
Input power
W
\
COP
W/W
\
Rated input (Whole units)
W
19,200
Rated current (Whole units)
A
32.5
Indoor air flow
m
3
/h
6,060
Indoor noise level
dB(A)
65
Refrigerant type
\
R410A
Refrigerant control
\
Capillary
Fan
Type
\
Centrifugal fan
Motor model
\
YSK600-6
Motor input(hi/med/lo)
W
790/670/580
Capacitor
\
30μF/450V
Motor speed(hi/med/lo)
rpm
890/790/700
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф9.52
No. of rows
\
3
Tube pitch(a)×row pitch(b)
mm
25.4×22
Fin spacing
mm
1.6
Coil(W×H)
mm
982×711.2
Number of circuits
\
14
Controller
\
R51/CE
Refrigerant pipe (Liquid/ Gas)
mm
Ф12.7/Ф28.6
Drain pipe size
mm
Ф41
Dimension (W×H×D)
mm
1,200×1,860×420
Packing (W×H×D)
mm
1,362×2,050×582
Net/Gross weight
kg
148/174
Notes:
1. Nominal cooling capacities are based on the following conditions:
T1: Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; T3: Indoor temp: 27°CDB, 19°CWB;
Outdoor temp: 46°CDB; Equivalent refrigerant piping: 7.5m (horizontal).
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB; Equivalent refrigerant piping: 7.5m
(horizontal).
