Midea MTA-76C(H)RN1 User Manual

Midea R410A T3 Top-discharge Split Type Series 50Hz MCAC-UTSM-201501
61
Model
MOV-120HN1-C
MOV-120CN1-C
Power supply
\
380-400V~, 3Ph, 50Hz
Ambient temp in cooling
°C
17～52
17～52
Ambient temp in heating
°C
-7~24
/
Rated input (Whole units)
W
17,300
17,300
Rated current (Whole units)
A
28.6
28.6
Noise level
dB(A)
69
69
Compressor
Type ×Qty.
\
Scroll ×1
Scroll ×1
Brand
\
Danfoss
Danfoss
Model
\
SH140A4ALC
SH140A4ALC
Capacity
W
34,700
34,700
Input
W
10,862
10,862
Rated current
A
21.4
21.4
Locked rotor Amp
A
147
147
Refrigerant oil
ml
3,300
3,300
Refrigerant
Type/Charge
\
R410A/7,200g
R410A/7,200g
Fan
Type ×Qty.
\
Axial fan ×2
Axial fan ×2
Motor model
\
YDK400-4C
YDK400-4C
Motor input
\
Hi: 621/587; Lo: 388/388
Hi: 621/587; Lo: 388/388
Capacitor
\
25μF/450V
25μF/450V
Motor speed
rpm
Hi: 1,180/1,230; Lo: 790/870 (4/3 fan blades)
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7
Ф7
No. of rows
\
3
3
Fin space
mm
1.3
1.3
Tube pitch(a)×row pitch(b)
mm
21×13.37
21×13.37
Coil (W×H)
mm
(1,380×882)+(1,380×882)
(1,380×882)+(1,380×882)
Number of circuits
\
20+20
20+20
Refrigerant
pipe
Liquid side/ Gas side
mm
Ф12.7/Ф28.6
Ф12.7/Ф28.6
Max. pipe length
m
50
50
Max. difference in level
m
30(Outdoor unit down), 25(Outdoor unit up)
Connection
wire
Power wire (Indoor unit)
\
3×2.5mm
2
3×2.5mm
2
Power wire(Outdoor unit)
\
5×6.0mm
2
5×6.0mm
2
Power wire(Double outdoor
units, as power-main)
\
/
/
Signal wire
\
4×1.0mm
2
2×1.0mm
2
Dimension (W×H×D)
mm
1,260×908×700
1,260×908×700
Packing (W×H×D)
mm
1,320×1,060×730
1,320×1,060×730
Net/ Gross weight
kg
201/217
199/215
Notes:
Nominal cooling capacities are based on the following conditions: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 35°CDB; Nominal heating capacities are based on the following conditions: Indoor temp: 20°CDB;
Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. piping: 7.5m (horizontal).
