18
2) Indoor Unit Address Setting:
Once in the address setting page, press the button to enter the Send page. In Send page, press ▲ and ▼ to
adjust the address up and down respectively. Press to send the address to the indoor unit. (See Figure 4.3)
Figure 4.3
Field Settings
1) Conguration Method:
Long press and on the remote controller at the same time for 5 seconds to go to the parameter settings
status (see Figure 4.4);
Figure 4.4
2. Parameter Conguration for Remote Controller
