Midea RM12D

3
4. Installation and Fixing
Figure 2.3
Installation
1) Use the screws (accessories) to x and secure the remote controller bracket in a stable position (see Figure 2.3);
Make sure you refer to "1. Installation Precautions" to determine the location.
2) Slot the screw lid into the bracket cover on top of the screws (see Figure 2.4);
Figure 2.4
3) Slide the remote controller vertically down into the remote controller bracket (see Figure 2.5).
Figure 2.5
