Page 6
midlandusa.com
Model MXT500
1. Using the mounting bracket as a
template, mark the location of each
screw hole under the dash. Use a
nail or other sharp pointed object to
mark the hole locations.
2. Attach the bracket to the dash with
the Phillips head sheet metal screws
provided. Tighten the screws
securely. DO NOT OVER-TIGHTEN.
3. Once the bracket is secured to
the vehicle, slide the radio into the
bracket. Be sure the radio locks into
the bracket so it does not shift while
the vehicle is in motion.
INSTALLING THE MOUNTING BRACKET
3
~I
OLAN
r::/
____________
_
0
