3 – Out Of Vehicle Test CPX-900
3 – Out Of Vehicle Test
Out Of Vehicle
Test
Use Out Of Vehicle Test to test and verify the condition of a batteries that is not
connected to a vehicle..
IMPORTANT: To expidite the testing procedure, makes sure Auto Test is enabled.
(Chapter 6 - Settings) The testing process begins as soon as the clamps are connected.
The CPX-900 provides a battery decision along with additional detailed information on battery
cranking and reserve capacity. Press to return to the previous screen, select options and
when necessary,
to enter or continue to the next step.
Battery Test
1. Connect the tester clamps to the battery terminals.
2. Auto Test - If enabled, the tool immediately begins testing the battery. (See Chapter 6 - Settings)
NOTE:
The testing process uses Conductance Proling™ technology to determine
battery cranking capability and Reserve Capacity. This additional analysis can take
up to 60 seconds to complete.
3. At the Main Menu select Out Of Vehicle Test. The Battery Test begins immediately.
4. Enter Work Order - (if enabled) Use displayed template to Enter Work Order information.
5. Battery Test Setup - Edit the displayed battery information. Select Start to begin the testing
process.
Application Automotive
4D/8D
Group 31
Battery Post Top Post Side Post
Battery Type Flooded
AGM Spiral
EFB
AGM
Gel
Battery Units CCA
DIN
IEC
MCA
CA
SAE
EN
EN2
Battery Rating
Hold down or to increase
scrolling speed.
To Next Page
