Chapter 1: IntroductionDSS-7000
7. Enter the address and server information the analyzer will
use for sending test results via email.
8. Enter the Shop Information including the Store Name,
Street Address, City, State, Zip Code, and Phone #. Tap
Continue to advance to the next screen.
9. The user sign-on screen is displayed. Select a user to be-
gin using the analyzer.
NOTE: By default, the rst user created is as-
signed Administrator rights. Tap Add User to add
additional users. See Chapter 6: Setup for more
information.
User Interface
Home Screen
Menu Bar Android Icons
Selection Area
Menu Bar
Home: Return to the main user screen.
Messages: Displays important system messages including any
analyzer software updates and any scheduled battery tests.
History: Displays a history of tests performed by the tool. See
Chapter 5: History.
Support: Access to the analyzer’s Instruction Manual.
: Access the analyzer’s user defaults and settings in-
cluding WiFi setup, congured printers, system and
keyboard language, display brightness, system vol-
ume, connected accessories, and device information.
Selection Area
Displays the available test applications or testing functions.
Applications
