4 – Out Of Vehicle Test
CPX-900
19
5. Battery Test Setup - Edit the displayed battery information. Select Start to begin the testing
process.
Application Automotive
4D/8D
Group 31
Battery Post Top Post Side Post
Battery Type Flooded
AGM Spiral
EFB
AGM
Gel
Battery Units CCA
DIN
IEC
MCA
CA
SAE
EN
EN2
Battery Rating
Hold down or to increase
scrolling speed.
6. The CPX-900 will now run the Battery Test
, and display the test results.
7. Send Results - CPX-900 will present the option to enter an email address to send test results.
8. Remember to return CPX-900 to its docking station when testing is completed.
