Limiting the opening angle of the door
45
The door hinges are set ex works to
enable the door to be opened wide.
However if the opening angle of the
door needs to be limited for any reason,
the hinge can be adjusted to
accommodate this.
If the appliance door hits an adjacent
wall when opened, for example, the
opening angle can be limited toapprox.
90°.
The locking pins for limiting the door
opening must be fitted before the
appliance is installed.
The refrigerator section door must be
taken off in order to insert the pins into
the upper hinge of the freezer section
door.
Place the locking pins supplied for
limiting the door opening into the
hinges from above.
The door opening angle is now limited
to approx. 90°.
