Making the worktop cut-out and
building in the hob
Granite and marble worktops
e Worktop
f Hob
g Gap
As the ceramic glass and the
worktop cut-out have a certain
dimensional tolerance, gap g can
vary (min. 1 mm).
^
Make the worktop cut-out as shown
in "Building-in dimensions".
^
Feed the hob connection cable down
through the cut-out.
^
Centre the hob f in the cut-out.
^
Connect the hob to the mains.
^
Check that the hob works.
^
Seal the remaining gap g with a
silicone sealant that is heat-resistant
to at least 160 °C.
For granite and marble worktops,
only use silicone sealant that is
especially formulated for granite and
marble, and observe the sealant
manufacturer's instructions.
Flush-fitted hobs
56
