Installation and planning notes
24
Levelling
To ensure the ironer functions correctly and energy efficiently, it
must be levelled horizontally with the screw feet.
Dismantle the mounting flaps on the left and right sides.
Align the roller and the side columns using the screw feet and a
spirit level. The screw feet under the side columns can be un-
screwed to a maximum of 60mm.
After levelling the machine secure the screw feet so they cannot
come loose.
Floor anchoring
Suitable anchoring materials for the ironer are available as optional
accessories from the Miele Professional Service Department. Altern-
atively, the tensioning strips that secured the ironer to the transport
pallet for delivery may be used to anchor the machine to the floor.
40 mm
7.1 mm
12 mm
20 mm
30 mm
85 mm
100 mm
Tensioning strip from the transport pallet
