Miele PW 6321 - Dispensing-Agent Connection to the Mixer Compartment

Installation
64
 Attach the non-return valve to the faucet.
 Attach the water inlet hose to the thread of the non-return valve.
Dispensing-agent connection to the mixer compartment
Connections1 and2 are provided for viscous agents. These con-
nectors are sealed and need to be drilled open using an 8mm drill
bit.
Care must be taken to drill through the first wall(1) only, as there is a
deflecting wall(2) 3/8" (10mm) behind it.
If the drilled-out connections are no longer required, they must be re-
sealed.
