Technical Information
36
T1500 Series Clothes Dryers
5.12 Condenser Assembly – Removal
Service Tip
To access to The Condenser Pump and/or Float Switch; the
Condenser Assembly must be removed from the appliance.
1. Remove the Coupler between the Fan Motor Housing and the
Condenser Assembly.
2. Remove the Fan Motor (5.11)
3. Remove the Heat Exchanger form the Condenser (3.6).
4. Disconnect the electrical connections.
5. Slide the Condenser Assembly toward the front of the appliance
and lift to remove.
