T1500 Series Clothes Dryers – List of Figures
1-1 Overview T1500 Series Dryer 1
1-2 Typical Installation 2
1-3 Control Panels (T1515, T15120 & T1526) 3
1-4 Control Panels (T1565C, T1570C & T1576) 4
1-5 Appliance Dimensions (5 Kilogram - Vented 5
1-6 Appliance Dimensions (5 Kilogram - Condenser) 5
1-7 Appliance Dimensions (6 Kilogram) 6
1-8 Layout of Components (T1515, T1520, T1526, T1565C & T1570C) 7
1-9 Layout of Components (T1576) 8
3-1 Opening the Cover to the Heat Exchanger 14
3-2 Positioning the Heat Exchanger Levers 14
3-3 Removing the Heat Exchanger 15
3-4 Cleaning the Heat Exchanger 15
4-1 Vented Dryer Airflow 17
4-2 Condenser Dryer Airflow 18
4-3 Motor Assembly 20
4-4 Drum Drive Belt and Reduction Pulley 21
4-5 Heater Bank Assembly 24
4-6 Heater Circuit 24
4-7 Electronic Locations (T1515, T1520, T1526, T1565C & T1570C) 25
4-8 Electronic Locations (T1576) 26
5-1 Lid Removal and Front Panel Access 27
5-2 Removing the left section of the fascia panel 28
5-3 Securing screw for Power Electronic 29
5-4 Removing the Power Electronic on the T1576 30
5-5 Control Electronic Removal 31
5-6 Heater Relay Bracket 32
5-7 Drum positioned for Access to Bearing Bolts 33
5-8 Heater Bank Cover Retaining Bolts 34
5-9 Heater Bank Removal 34
5-10 Vent Ring Assembly 35
5-11 Fan Motor Bolts 35
5-12 Bottom Cover Screws 37
5-13 Condenser Fan Screws 37
5-14 Residual Moisture Sensor Mounting 38
5-15 Positioning the Drum for Drive Belt Installation 39
