Mighty Mule FM500 - Closed Position Stop Plate Installation

15
Mounting Pull-to-Open Opener to Gate
Gate Opener Installation
12
Y
S
T
R
1
1
2
2
13
Attach and secure opener assembly to brackets.Attach gate bracket assembly to gate cross support.
14
Check for level. Adjust post bracket if necessary.
Remove bolt excess length on post and gate bracket with
hacksaw.
15
Your Property
2
1
1
2
J
1
Fully open gate. Attach gate stop with one of the following:
• U-bolts—tube and chain link gates (Not included)
• Wood/lag screws—at aluminum/wood supports (Not included).
Do not tighten.
Position gate stop with gate CLOSED to fence post. Tighten
fasteners. Cut off excess bolt length.
Closed Position Stop Plate Installation
