Miller T94 Series User Manual

OM-255503 Page 14
5-4. Mode Control Settings
(R)
MEMO
(
B
)
1
2
1
2
1 Mode Button
2 External Grind Mode Button
Press Mode button to select the mode ap-
propriate for the work activity:
Weld Mode - used for most welding applica-
tions. In this mode the lens turns on when it
optically senses a welding arc. Adjust
shade, sensitivity, and delay settings as
needed.
Cut Mode - used for cutting applications. In
this mode the lens turns on when it optically
senses a cutting arc. Adjust shade, sensitiv-
ity, and delay settings as needed.
If nearby objects may inadvertently
contact the external Grind Mode but-
ton while you are welding, unplug
the Grind Mode button to prevent ac-
cidental activation of the Grind
mode.
Grind Mode - used for metal grinding appli-
cations. In this mode the shade is fixed
shade No. 3. No lens adjustments are
possible.
Use external Grind Mode button to select
grinding mode without raising helmet.
To use Grind mode, press and hold the ex-
ternal Grind button for two seconds. Press
Grind Mode button again to turn off Grind
mode.
X-Mode - used for outdoor or low current
welding applications. In this mode the lens
turns on when it senses weld current. Adjust
shade, sensitivity, and delay settings as
needed.
F
Nearby welding may affect helmet op-
eration when lens is in X-Mode. Stay
at least 12 ft (3.7 m) away from other
welding activity.
