Using the Elix System
Elix® 20, 35, 70 and 100 26
3-3 HOW TO VIEW THE ELIX SYSTEM PERFORMANCE
There are several parameters that can be seen using the DATA Button. These parameters are explained and shown below.
1. Start in PRODUCTION Mode. Press the DATA Keypad Button. If the Elix System is without a Polisher Upgrade Kit or
without a Loop Resistivity Cell, then the LCD will look like:
The Elix System Product Water Resistivity is
13.2 MΩ.cm. at 25 °C. The TOC is 21 ppb.
2. Start in PRODUCTION Mode. Press the DATA Keypad Button. If the Elix System is with a Polisher Upgrade Kit, then the
LCD will look like:
The post QGard TL Polisher resistivity is
> 15.0 MΩ.cm at 25 °C. The same water has a
temp. of 12 °C.
3. Start in PRODUCTION Mode. Press the DATA Keypad Button. If the Elix System is with a Loop Resistivity Sensor, then the
LCD will look like:
The Loop Water has a resistivity of 3.2 MΩ.cm and a
TOC value of 29 ppb. The Loop Water has a temp. of
19 °C.
The parameters shown in the next several displays are the same for any configuration of an Elix System.
4. When the PRODUCT QUALITY is shown, press the Bottom Keypad Button to see the RO Cartridge performance.
5. When the RO Cartridge performance is shown, press the Bottom Keypad Button to see the PRESSURE DATA.
The RO Cartridge performance is
shown here.
Feedwater pressure is 2.1 bar and the
applied RO pressure is 10.0 bar.
