Milnor MCT12E5 User Manual

Torque Requirements for Fasteners
PELLERIN MILNOR CORPORATION
Table 2: Torque Values for Standard Fasteners Larger Than 5/16-inch Diameters and No Lubricant
Dimension
The Grade of the Bolt
Grade 2
Grade 5
Grade 8
Grade BC
Pound-feet N-m Pound-feet N-m Pound-feet N-m Pound-feet N-m
3/8 x 16
20
27
31
42
44
59
38
52
3/8 x 24 23 31 35 47 50 68 -- --
7/16 x 14 32 43 49 66 70 95 61 83
7/16 x 20 36 49 55 75 78 105 -- --
1/2 x 13
49 66 75 102 107 145 93 126
1/2 x 20
55
75
85
115
120
163
--
--
9/16 x 12 70 95 109 148 154 209 134 182
9/16 x 18 78 106 121 164 171 232 -- --
5/8 x 11 97 131 150 203 212 287 186 252
5/8 x 18
110 149 170 231 240 325 -- --
3/4 x 10
172
233
266
361
376
510
329
446
3/14 x 16 192 261 297 403 420 569 -- --
7/8 x 9 167 226 429 582 606 821 531 719
7/8 x 14 184 249 473 641 668 906 -- --
1 x 8
250 339 644 873 909 1232 796 1079
1 x 12
274
371
704
954
994
1348
--
--
1 x 14 281 381 723 980 1020 1383 -- --
1 1/8 x 7 354 480 794 1077 1287 1745 1126 1527
1 1/8 x 12 397 538 891 1208 1444 1958 -- --
1 1/4 x 7
500 678 1120 1519 1817 2464 1590 2155
1 1/4 x 12
553
750
1241
1682
2012
2728
--
--
1 3/8 x 6 655 888 1469 1992 2382 3230 2085 2827
1 3/8 x 12 746 1011 1672 2267 2712 3677 -- --
1 1/2 x 6 869 1178 1949 2642 3161 4286 2767 3751
1 1/2 x 12
979 1327 2194 2974 3557 4822 -- --
Table 3: Torque Values for Plated Fasteners with Maximum 5/16-inch Diameters and No Lubricant
Dimension
The Grade of the Bolt
Grade 2
Grade 5
Grade 8
Grade BC
Pound-Inches N-m Pound-Inches N-m Pound-Inches N-m Pound-Inches N-m
1/4 x 20
49
6
76
9
107
12
95
11
1/4 x 28 56 6 88 10 122 14 -- --
5/16 x 18 102 12 156 18 222 25 193 22
5/16 x 24
113
13
174
20
245
28
--
--
46
