PELLERIN MILNOR CORPORATION
3
TOP
COSMETIC
COVER
7
PELLERIN MILNOR CORPORATION
3
7
GASKET
(NOT SHOWN)
2
1
5
4
APPLY SILICONE BETWEEN
SOAP CHUTE BODY AND COVER
CLIPS
(4 PLACES)
9
8
1
CHEMICAL
WATER
LINES
HOT WATER
TO FLUSH
SOAP CHUTE
PERISTALTIC
CHEMICAL
INLETS TO
SOAP CHUTE
6
MWR12E5, MWR16E5 MWT12E5, MWT16E5
MWT18E4, MWT18X4, MWT18J6, MWT27E5, MWT27X5, MWT27J5
MWR18E4, MWR18X4, MWR18J6, MWR27E5, MWR27X5, MWR27J5
PERISTALTIC
CHEMICAL
INLETS TO
SOAP CHUTE
6
COVER
BODY
10,11
Three Chemical Lines
HOT WATER
TO FLUSH
SOAP CHUTE
BMP060005/2016533A
Soap Chute for E-P One-Touch®
MWR12E5, MWR16E5, MWR18E4, MWR27E5
MWT12E5, MWT16E5, MWT18E4, MWT27E5
93
