Bearing Assembly & Installation
MWR18X6, MWR18J6
MWT18X6, MWT18J6
SHELL
BACK
VIEW A-A
B
B
WATER
SEAL
HOLDER
7,8,98,9,10
11,12,13
VIEW B-B
CYLINDER
BACK
PLATE
3
1
2
WATER
SEAL
HOLDER
A
SHELL BACK
SHAFT
SEALED
BALL
BEARINGS
A
LEAK OFF
Lubricate the O-rings with the
approved grease before installation
4
BEARING
Fully fill
the area
between
the seals
with the
approved
grease
6
5
14
15,16,17,18
19
20
21
22
23
62
