PELLERIN MILNOR CORPORATIONPELLERIN MILNOR CORPORATION
Figure 1: Drive Components
Drive Chart
MCR12E5, MCR16E5, MCR18E4, MWR12E/X/J5, MWR16E/X/J5, MWR18E/X4, MWR18J6
MCT12E5, MCT16E5, MCT18E4, MWT12E/X/J5, MWT16E/X/J5, MWT18E/X4, MWT18J6
1
2
3,4
5
6
See page 2 and Detail A for
“How to Tighten the Pulley Bushing
Against the Motor Shaft”.
BMP050008/2016533A
54
