Milnor MCT12E5 User Manual

Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
partslist to the illustration.
Parts List—Drive Chart
PELLERIN MILNOR CORPORATION
Page (3 / 3)BMP050008/2016533A
Drive Chart
------------------------------------------------------------------------------ASSEMBLIES--------------------------------------------------------------
A D33 03760 DRIVE CHART MCR09E5 MCR12E5, MWR12E5
MCT12E5, MWT12E5
B D33 03960 DRIVE CHART MCR16/MWR16 MCR16E5, MWR16E5
MCT16E5, MWT16E5
C D33 03660 DRIVE CHART MCR18E4 MCR18E4, MWR18E4
MCT18E4, MWT18E4
MWR18X4,MWR18J4
MWT18X4, MWT18J4
----------------------------------------------------------------------------COMPONENTS-------------------------------------------------------------
AB 1 98CMCR0917 VPAUL TB BUSHING SPZ 355X2
C 1 98CMCR1817 VPAUL TB BUSHING SPZ 500X2
A 2 98CMCR0909 SINGLE DRIVE BELT SPZ1362LW
B 2 98CMCR1609 SINGLE DRIVE BELT SPZ1340LW
C 2 98CMCR1809 SINGLE DRIVE BELT SPZ1937LW
AB 3 98CMCR0918 BUSH TB TYP 2012X38, BSW7/16"
C 3 98CMCR1818 BUSH TB TYPE 2517X38, BSW7/16”
all 4 98CMCR0919 KEY 10*8*60 — 15E230CM
AB 5 98CMCR0920 VPAUL TB BUSHING SPZ 56X2
C 5 98CMCR1820 VPAUL TB BUSHING SPZ 67X2
A 6 98CMCR0921 BUSH TB TYP 1108X19, BSW1/4" S
B 6 98CMCR1621 BUSH TB TYP 1108X24, BSW1/4”
C 6 98CMCR1821 BUSH TB TYP 1108X28, BSW1/4”
MCR12E5, MCR16E5, MCR18E4, MWR12E/X/J5, MWR16E/X/J5, MWR18E/X4, MWR18J6
MCT12E5, MCT16E5, MCT18E4, MWT12E/X/J5, MWT16E/X/J5, MWT18E/X4, MWT18J6
56
