Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
partslist to the illustration.
Parts List—Level Switch
PELLERIN MILNOR CORPORATION
Page (2 / 2)
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
All 1 09N089 PRESS SW ASSY TRIP 4.7
all 2 09N086A PRESS SW INVENSYS #738-761
all 3 09N100 PRESS SW ASSY TRIP 2.5"
all 4 09N101 PRESS SW ASSY TRIP 4.85"
all 5 5SB1A0PNFO NPTHEXBUSH 1X3/4 GALMAL 150#
all 6 5SB0P0GNFO NPTHEXBUSH 3/4X3/8 GALMAL 150#
all 7 51E507A HOSESTEM BRASS 3/8MPX1/2HOSEID
all 8 27A040 HOSECLAMP 7/16-25/32SS W/SCREW
all 9 60E005P PVC TUBING 1/2"ID X 5/8"OD
BMP050006/2016533A
Level Switch
MCR12E5, MCR16E5, MCR18E4, MWR12E/X/J5, MWR16E/X/J5, MWR18E/X4, MWR18J6
MCT12E5, MCT16E5, MCT18E4, MCT27E5
MWT12E/X/J5, MWT16E/X/J5, MWT18E/X4, MWT18J6, MWT27E/X/J5
85
