6.5 PARTS LIST FOR MROY ECC MOUNTING ADAPTER
Model: mRoy “B”
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REF
CODE
17 - Kit, ECC Retrofit -19/32 Plunger 3351402020 1
- Kit, ECC Retrofit -7/8 Plunger 3351402030 1
- Kit, ECC Retrofit - 1-7/16 Plunger 3351402040 1
140 Plug Assembly, Adapter 1-1/4” NPT,
1-7/16 Plunger
2430045030 1
140 Plug Assembly, Adapter 3/4” NPT,
19/32 and 7/8 Plunger
2430045010 1
150 O-Ring, Cont. Spool, 2-011 Ure-
thane
4080068032 3
160 Spool, Control 2680049006 1
170 Sleeve, Threaded 2430059051 1
180 Screw, Socket Set 6-32NCx1/4 4050039035 1
190 Decal, Capacity 2530026062 1
200 Ring, Calibration - Aluminum 2530025062 1
210 Knob, Capacity Adjust - Delrin 2550036077 1
213 Bearing, Control Spool 2370075052 1
217 Washer, Thrust 1/2” - Steel 4040147051 1
220 Clip, E-Ring External 4049983151 1
810 Coupling, Drive 2520120077 1
820 Lock-Washer, Internal Tooth #8 4040104082 2
830 Screw, Pan Hd #8-32NC x 1/2” 4050179073 2
840 Bracket, Mounting - Steel 2040148006 1
850 Stud, Mounting 2320033006 1
860 Nut, Serrated Flange 1/4-20NC 4050323036 1
880 Screw, Socket Head 5/16”-18x5/8 4050157024 1
900 ECC See Table 2 1
910 Shaft Assembly, Drive: Includes
Items 910, 915 & 920
2680054000 1
910 Shaft, Drive - Delrin 2680053077 1
915 Pin, Dowel 1/8 x 1-3/8 Steel 4010021143 1
920 Pin, Spring 0.187 x 13/16 CRS 4010005062 1
930 Lock-Washer, Spring 3/8” 4040041022 4
935 Screw, Hex Hd 3/8-16 x 3/4 4050018096 4
950 Guards, Side 2490108006 2
970 Screw, Bottom Head #10-32x 5/16 4050282087 4
1450 Label, Warning 2530097000 1
