Milton Roy MAXROY B - Page 48

40
6.6 PARTS LIST FOR MACROY ECC MOUNTING ADAPTER
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REFERENCE
CODE
18 - Kit, ECC Retrofit Mount Mil G 20625 1 B
160 O-Ring, 1.984 x 0.139, Buna N 4080095171 1 A, B, C
- Stroke Screw Assy, See Note 60293 1 A, B
165 Pin, Spring 4910764012 1 A, B
166 Pin, Dowel, See Note 4010021030 1 A, B
- Screw, Socket Hd, 6-32NC x 3/
8, See Note
4050204034 4 A, B
- Screw, Stroke Adjust, See Note 60948 1 A, B
- Retainer, Bearing, See Note 60949 1 A, B
170 Screw, Stroke Adjust, See Note 60442 1 A, B
170 Screw, Stroke Adjust 61261 1 C
172 Plug, Stroke, See Note 60283 1 A, B
174 Sleeve, Shaft, See Note 60284 1 A, B
175 Scale, Stroke 2530046062 1 A, B
181 Insert, Stroke Screw, See Note 60285 1 A, B
190 O-Ring, Parker 2-246, Buna N 4080095371 1 A, B
200 Cover 60986 1 A, B
200 Cover 61255 1 C
201 Scale, Stroke 61268 1 C
205 Screw, Socket Hd M8 x 35 mm 4350035542 4 A, B
205 Screw, Socket Hd M6 x 45 mm 41567 3 C
206 Lock-washer, Spring 8 mm 4340009002 4 A, B
320 Screw, Socket Set M6 x 6 mm 41067 1 C
330 Knob, Stroke Adjust 60286 1 A, B
332 Screw, Socket Hd M6 x 30 mm 4350047395N 2 C
500 Rod, Stroke Drive 60287 1 A, B
500 Coupling, Drive - D/SD ECC 61247 1 C
504 Pin, Connecting 60290 1 A, B
504 Pin, Dowel, 3/16 X 2 4010022082 1 C
505 Ring, Retaining 40203 2 A, B
- Item not shown.
Model: Code:
MacRoy “G” A
Milroyal “G” B
Model:
Code :
MacRoy “D” C
