41
NOTE Part not sold separately. Replacement requires purchase of “GB ECC Stroke Screw Assembly”
(part number 60293) made up of items: 165, 166, 170, 172, 174, and 181.
506 Ring, Retaining 40204 2 A, B
507 Pin, Connecting 60971 1 A, B
510 Coupling 60970 1 A, B
510 Shaft, Drive 2680063062 1 C
510 Coupling, Drive Shaft 61123 1 C
515 Bracket, Mounting 60289 1 A, B
515 Bracket, Mounting 61245 1 C
517 Guard, Side 2490108006 1 A, B
517 Guard, Modified 61244 1 C
519 Guard, Modified Side (Slotted) 60292 1 A, B
520 Screw 4050282087 4 A, B
520 Screw, Btn Hd Soc, #10-32X3/8 4050282027 2 C
530 ECC See Table 8 1 A, B, C
531 Screw, Hex Hd 3/8-16 x 3/4 4050018096 4 A, B, C
532 Lock-washer, Spring 3/8 4040041022 4 A, B, C
540 Spacer MIL G Act Mtg Bracket 60985 4 A, B
540 Standoff - D/SD ECC 61246 3 C
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REFERENCE
CODE
- Item not shown.
