6.10 PARTS LIST FOR MILROYAL ECC MOUNTING
Model: Milroyal “D”
MOUNTING PARTS LIST
FIGURE
NUMBER
ITEM
NUMBER
DESCRIPTION PART
NUMBER
QUANTITY REFERENCE
CODE
22 - Kit, ECC Retrofit Mount 30265 1
190 Screw, Lead 2560027006 1
240 Scale, Stroke 2530046000 1
350 Bracket, Mounting 2040187006 1
351 Lock-washer, Spring 4040039022 4
352 Nut, Hex 1/4 - 20NC 4050064012 4
360 Ring, Calibration, Aluminum 2530025062 1
405 Stud, Mounting 2320034006 4
410 Shaft, Drive 2680063062 1
413 Pin, Spring 0.187 x 13 x 16 4010005062 1
414 Pin, Dowel 3/16 x 1-3/4 4010022072 1
415 Coupling, Drive 2520154077 1
417 Pin, Spring 0.125 x 1-1/2 4010003152 1
420 ECC See Table 6 1
421 Lock-washer, Spring 3/8 4040041022 4
422 Screw, Hex HD 3/8-16 x 3/4 4050018096 4
- Items not shown.
