MIMAKI CG-130FXII User Manual

– 3.68 –
In use of the undetectable sheet [SHEET sensor]
The sheet sensor detects the presence/absence of a sheet and the sheet length. Two sheet sensors are
mounted on the platen.
In the case where any of the following types of sheet is used, the sheet sensors will not be able to
detect it to give the error message shown below.
•Transparent sheet that does not reflect the light coming from the sheet sensor.
• The sheet of which wrong side is black that does not reflect the light coming from the sheet
sensor.
In this case, cutting is enabled by setting the [SHEET SENSOR] function contained in the SET UP
of FUNCTION to OFF.
Setting value
OFF : The sheet sensor function is rendered ineffective.
ON : The sheet sensor function is rendered effective.
* In the case where the [SHEET SENSOR] function is set to the OFF state, a
cutting area has to be established since the device may cut data that ex-
ceeds the sheet or continue cutting if there is no sheet left.
**
NO SHEET
**
Sheet sensor

MIMAKI CG-130FXII Specifications

General

Type	Cutting Plotter
Maximum Cutting Width	1300 mm
Cutting Speed	1000 mm/s
Repeatability	±0.1 mm
Power Supply	AC 100-240V, 50/60Hz
Weight	75 kg
Maximum Media Width	1370 mm
Maximum Cutting Area	1300 mm x 50 m
Cutting Force	30 - 500 gf
Maximum Cutting Force	4.9 N (500 gf)
Media Thickness	0.1 mm
Interface	USB, Ethernet
Operating Temperature	5 - 35 °C
Operating Humidity	35 - 80 %
Power Requirements	AC 100-240V, 50/60Hz
