Mimosa Backhaul Help Content
Mimosa Backhaul LED Status Indicators
Copyright © 2014 Mimosa Page 194
Off Not Associated (No Link)
Solid Blue Associated (Linked)
Blinking Blue Associated; Blink rate proportional to signal strength*
* Ranges from 1 Hz (one blink per second at -90 dBm or less) to 10 Hz (one blink per 100 ms at -50 dBm or greater).
