Mimosa Backhaul Help Content
Mimosa Backhaul B5/B5c
Copyright © 2014 Mimosa Page 212
Firmware Version 1.3.0
March 1, 2016
Product Applicability: B5, B5c, B5-Lite, B11
March 7, 2016: Firmware version 1.3.0 was removed because of a performance impacting bug that was
March 7, 2016: Firmware version 1.3.0 was removed because of a performance impacting bug that was
just discovered. B5, B5c, and B5-Lite are affected. We intend to release version 1.3.1 to correct the bug
just discovered. B5, B5c, and B5-Lite are affected. We intend to release version 1.3.1 to correct the bug
shortly. In the mean time, please continue to use firmware version 1.2.3.
shortly. In the mean time, please continue to use firmware version 1.2.3.
New Features
Support for B11
Mimosa's latest licensed backhaul product supporting 10-11 GHz and fiber connectivity. (B11)
Low Latency Auto Mode
Redesigned MAC with elastic transmit slots to minimize latency and maximize throughput for traditional links (not
GPS synchronized). The default configuration is 4ms, and this value cannot be changed. This is the only mode
available for B5-Lite.
Dual Link Interference Avoidance
Dynamically routes traffic to channel with least PER to improve noise immunity and prevent packet loss. (B5, B5c,
B11)
Auto Power Optimization
Automatically adjusts Tx power to avoid compression and improve (minimize) EVM when SNR allows. (B5, B5c, B11)
Extended Frequency Range to 6.2 GHz
Channel selections from 6000 to 6200 MHz where regulations allow. (B5c, B5-Lite)
Remote Antenna Gain Input
Set both local and remote antenna gain on AP to improve signal target and Aiming Mode accuracy. (B5c, B11)
GPS Interference Mitigation
Maintains link stability at all times with an internal timer in varying GPS conditions. (B5, B5c, B11)
User Interface
Enabled Site Survey for AP mode.
●
Added "Off" selection to LED Brightness options.
●
Increased detail for GPS and unlock event messages.
●
Added null VLAN ID validation check.
●
