Mindeo CS2190 - Page 30

21
Example 3: Three handheld units and one cradle
The following takes channel No.5 for instance.
Step 1): Set Handheld unit RF channel No. of three handheld units to 5.
or
Step 2): Set Handheld unit address of the first handheld unit to 0002.
Step 3): Set Handheld unit address of the second handheld unit to 0003.
