Mindeo CS3290-2D - Page 33

21
Multiple-scan setting
Single-scan setting
Option bar code
Option
Alpha. entry
Wireless network topology for
cradle※
Point coordination
00*
*
Distributed coordination
01
Cradle RF channel No.※
02-16
02-16
06*
*
Bind the first handheld unit ID※
01-16
01-16
01*
Recruit a next handheld unit ID※
01-16
01-16
Radio power level for cradle
10 dbm
01*
*
7 dbm
02
5 dbm
03
0 dbm
04
-5 dbm
05
-10 dbm
06
-15 dbm
07
Show channel information of Cradle※
Note: The settings indicated with (※) are valid only when the cradle is in upgrade ready mode.
Cradle entering upgrade ready mode
Keep pressing the S button on the cradle, until the blue LED is flashing. Then three LEDs will all be
turned ON, this indicates the cradle being upgrade ready mode.
