8-25
SN Description FRU part number
9 Encoder board 0010-30-43089
10 Encoder cable 9200-21-10460
15 Touchscreen control board PCBA 051-000881-00
16 Cable between main board and keypad board 009-001982-00
17 Cable between the touchscreen control board and the main board 009-001981-00
18 Inner hexagon screw, M3×6 /
19 cPM 12 main board service kit 115-033303-00
20 Cable between the main board and backlight board (12") 009-001988-00
21 Cable between main board and alarm lamp board 009-002203-00
22 Signal cable for 12" screen 009-001985-00
23 12" LCD service kit 801-9221-00008-00
24 Touch-panel, resitive-type, 12.1" 4-line 021-000059-00
25 Screw, self-tapping, PT3×8 /
26 Keypad board PCBA, 12 inch 051-000889-00
27 Power button 049-000366-00
29 12" button (English) 049-000365-01
30 Screw, Pan head with washer, Phillips M3×6 /
31 Industrial SD card (SLC), 1G 023-000755-00
8.5.3 Rear Housing Assembly
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.3 Rear Housing Assembly.
8.5.4 Battery Compartment Assembly
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.5 Battery Compartment
Assembly.
8.5.5 Multi-parameter Assembly
For the exploded view and parts list of the multi-parameter assembly, refer to section 8.2.4 Multi-parameter
Assembly.
8.5.6 NIBP Pump and Valve Kit
For the exploded view and parts list of the NIBP pump and valve kit, refer to section 8.2.6 NIBP Pump and Valve Kit.
8.5.7 IBP_C.O. Module Assembly
For the exploded view and parts list of the IBP_C.O. module assembly, refer to section 8.2.7 IBP_C.O. Module
Assembly.
