6.6.7 Recorder Failures
Symptoms Possible Cause Corrective Action
No printout Recorder module
disabled
1. Check if the recorder status indicator lights.
2. If yes, enable the module in the [Factory Maintenance] menu.
Otherwise, check for other possible causes.
Paper reversed Re-install the paper roll.
Cable defective Check that the cable between the recorder and main board is correctly
connected.
Recorder defective Replace the recorder.
Poor print quality or
paper not feeding
properly
Paper roll not properly
installed
Stop the recorder and re-install the paper roll.
Print head dirty 1. Check the thermal print head and the paper roller for foreign matter.
2. Clean the thermal print head with an appropriate clean solution.
Recorder defective Replace the recorder.
6.6.8 Output Interface Failure
Symptoms Possible Cause Corrective Action
No analog out signal
Cable defective
1. Check that the cable between the multi-parameter board and
power management board is correctly connected.
2. Check that the cable between power management board and
interface board is correctly connected.
Multi-parameter board failure Replace the multi-parameter board
Power management board
defective
Replace the power management board.
The connector board failed. Replace the connector board .
Unable to use the
USB devices
USB drive data
transfer failure
Cable defective
1. Check that the cable between the power management board
and main board is correctly connected.
2. Check that the cable between power management board and
interface board is correctly connected.
The connector board failed. Replace the connector board.
Power management board
defective
Replace the power management board.
The main board failed. Replace the main board.
Improper setup
Select [Main Menu]→[Maintenance >>]→[User
Maintenance >>]→enter the required password→ [Others >>]
and set [Data Transfer Method] to [USB Device].
