Mindray Eagus R9 User Manual

Specifications 2-3
No. Name Function
<11>
Rotatable knob on the
control panel
Lock or unlock the movement of the control panel
<12>
Ascending/descending
button
The button to ascending or descending the system.
<13> Control panel
Key- pressing operator-system interface or accessible to
control
<14>
Transducer (gel) holder
Used for placing transducers and gel temporarily.
<15> Monitor support arm
Supports the monitor, for adjusting the angle of LCD
monitor.
<16>
The control panel
stretch mechanism
Used for stretching or rotating the control panel.
Note: subject to the Control Panel Moving Mechanism
Assembly when the user purchases the product.
<17>
Motor-driven lift
mechanical assembly
Used for adjusting the height of the control panel
<18>
The back handle of
main unit
Used for winding the cables up and assisting for moving the
system.
<19> I/O Panel Port panel for input and output signals.
<20>
Power supply assembly
for the system
Provides the power to the system.
