Specifications 2-5
2.1.2.2 Power Supply Panel
No. Name Function
<1>
current auxiliary
output
Supply power for optional peripheral devices.
<2> Circuit breaker Used for switching off/ on the power supply.
<3> Power inlet AC power inlet
<4>
terminal
Used for equipotential connection, that balances the protective earth
potentials between the system and other electrical equipment.
