System Diagnosis and Support 11-11
T011
DSP Tj
Engine Board
F001 Fan_80_J6 Inlet fan assembly ［FAN_IN_TACH0（J6）]
F002 Fan_80_J6 Inlet fan assembly ［FAN_IN_TACH1（J6）]
F003 Fan_80_J6 Inlet fan assembly ［FAN_IN_TACH2（J6）]
F004 Fan_60_J3
Inlet fan assembly ［FAN_IN_TACH3(J3)]
F005 Fan_60_J3
Inlet fan assembly ［FAN_IN_TACH4(J3)]
F006 Fan_60_J1 Inlet fan assembly ［FAN_IN_TACH5(J1)]
F007 Fan_60_J1 Inlet fan assembly ［FAN_OUT_TACH0(J1)]
F008 Fan_120_J2 Inlet fan assembly ［FAN_OUT_TACH1(J2)]
F009 Fan_120_J4 Inlet fan assembly ［FAN_OUT_TACH2(J4)]
F010 Fan_CPU GPU Fan
F011 Fan_GPU GPU Fan
I001 DC-DC 7462 DC Box Assembly
I002
PC carrier board
7462_A
PC carrier board Assembly
I003
PC carrier board
7462_B
PC carrier board Assembly
E001 EL_S_Protect Height Control Panel Assembly
E002
EL_H_Protect
Height Control Panel Assembly
E003
Upkey
Height Control Panel Assembly
E004 Downkey Height Control Panel Assembly
E005
MoveKey
Height Control Panel Assembly
E006 Motor_Sensor Height Control Panel Assembly
E007
Motor_OVP
Height Control Panel Assembly
E008 Motor_UVP Height Control Panel Assembly
E009
Motor_OSP
Height Control Panel Assembly
E010
Motor_ComErr
Height Control Panel Assembly
E011
Motor_ComErr_
S
Height Control Panel Assembly
E012
Key_Stuck
Top Cover Assembly of the Keyboard
P001 PHV1P
PHV box assembly
Source: PHV box assembly
Load: TR board
P002 PHV1N
PHV box assembly
Source: PHV box assembly
Load: TR board
P003 PHV2P
PHV box assembly
Source: PHV box assembly
Load: TR board
