5-80 Image Optimization
2. Tap [SmartFace] to enter the function and the system adjust fetal face angle (fetal head facing up)
automatically and remove the shading obstacle data.
3. Tap the button to enter Setup screen. Adjust parameters as described below.
Parameter adjusting
Parameters under Smart Face are similar to those under Static 3D mode. For details, refer to “5.11.3.3
Static 3D Image Viewing”.
MixRender/SubTint
The higher the merge value, the clearer the shading obstacles on the image.
If the value is set 0, no obstacle data will be displayed.
Operation
Tap the button to enter Setup screen, tap [MixRender] to select the
levels between 0-3.
Tap [SubTint] to select the obstacle display color.
Impacts This function is available only under “Surface” mode.
Eraser
Description
Clearing effect in the center of the eraser sphere is strongest, and this effect
weakens along the sphere center to the edge.
Tap [For Rubber] to erase existing data on the screen.
Tap [Re-Rubber] to restore those removed shading data.
Tap the button to enter Setup screen, tap [EraseSize] to select the size:
Small, Middle, Large.
Select different clearing manner: [For Rubber] / [Re-Rubber].
Tap [Undo] to undo the operation in sequence and tap [Undo All] to undo all
erase effects.
Impacts This function is available under “Surface” mode.
AutoDirect
Description
This feature allow you to optimize to a best observing angle of view within one
step.
The recommended angle: fetal head is facing up and the face is at the front
with [Direction] to be up/down.
Tap the button to enter Setup screen and select [AutoDirect].
FaceContact
Description The higher the value, the more adjacent the VR image is to the fetal face, and
the more obstacles cleared.
The lower the value, the further the VR image is to the fetal face, and the less
obstacles cleared.
Operation Rotate [FaceContact] to adjust the parameter.
VR Orientation
Description Rotate the image quickly.
