Panorama® Service Manual 0070-10-0634 1 - 5
Instrument Description Panorama Block Diagrams
1.2 Panorama Block Diagrams
The following block diagrams illustrate wired and wireless (ISM, WMTS) configurations for
the Panorama Patient Monitoring Network.
1.2.1 Wired
FIGURE 1-1 Panorama Patient Monitoring Network (Wired)
Printer
Panorama Central Network
C-LAN
Switch
Display Display
Switch
Display Display
PANORAMA
Central
Station
16 Patient
PANORAMA
Central
Station
16 Patient
Pass
p
ort 2 - 1 Pass
p
ort 2 - 2 Pass
p
ort 2 - 16
100 Base T E-LAN
Patient Network
Pass
p
ort 2 - 1 Pass
p
ort 2 - 2 Pass
p
ort 2 - 16
100 Base T E-LAN
Patient Network
