Panorama Motherboard CMOS Setup/Verification Appendix A
7 - 6 0070-10-0634 Panorama® Service Manual
IRQ-12 ASSIGNED TO: PCI/ISA PnP
IRQ-14 ASSIGNED TO: PCI/ISA PnP
IRQ-15 ASSIGNED TO: PCI/ISA PnP
DMA-0 ASSIGNED TO: PCI/ISA PnP
DMA-1 ASSIGNED TO: PCI/ISA PnP
DMA-3 ASSIGNED TO: PCI/ISA PnP
DMA-5 ASSIGNED TO: PCI/ISA PnP
DMA-6 ASSIGNED TO: PCI/ISA PnP
DMA-7 ASSIGNED TO: PCI/ISA PnP
PCI IDE IRQ MAP TO: PCI-AUTO
PRIMARY IDE INT#: IDE INT#: A
SECONDARY IDE INT#: IDE INT#: B
USED MEM BASE ADDR: NA
INTEGRATED PERIPHERALS
IDE HDD BLOCK MODE: ENABLED
IDE PRIMARY MASTER PIO: AUTO
IDE PRIMARY SLAVE PIO: AUTO
IDE SECONDARY MASTER PIO: AUTO
IDE SECONDARY SLAVE PIO: AUTO
IDE PRIMARY SLAVE UDMA: AUTO
IDE SECONDARY MASTER UDMA: AUTO
IDE SECONDARY SLAVE UDMA: AUTO
ON-CHIP PRIMARY PCI IDE: ENABLED
ON-CHIP SECONDARY PCI IDE: ENABLED
ONBOARD PCI SCSI CHIP: DISABLED
USB KEYBOARD SUPPORT: DISABLED
WATCHDOG TIMER: DISABLED
WDT TERMINAL VALUE: 7
KBC INPUT CLOCK: 8 MHZ
ONBOARD FDC CONTROLLER: ENABLED
ONBOARD SERIAL PORT 1: 3F8/IRQ4
ONBOARD SERIAL PORT 2: 2F8/IRQ3
UR2 MODE: STANDARD
ONBOARD PARALLEL PORT: 378/IRQ7
PNP/PCI CONFIGURATION (CONTINUED)
PNP OS INSTALLED: NO
