Panorama® Service Manual 0070-10-0634 7 - 9
Appendix A Panorama Motherboard CMOS Setup/Verification
USB Keyboard Support Disabled
AC97 Audio Auto
Init Display First PCI Slot
IDE HDD block Mode Enabled
POWER ON Function BUTTON Only
X Hot Key Power On Ctrl-F1
Onboard FDC Controller Enabled
Onboard Serial Port 1 3F8/IRQ4
Onboard Serial Port 2 2F8/IRQ3
UART Mode Select Normal
Onboard Parallel Port 378/IRQ7
Parallel Port Mode SPP
PWRON After PWR-Fail Off
Onboard Serial Port 3 3E8H
Serial Port 3 Use IRQ IRQ5
Onboard Serial Port 4 2E8H
Serial Port 4 Use IRQ IRQ10
Digital I/O Disabled
POWER MANAGEMENT SETUP
ACPI Function Enabled
Power Management User Defined
Video Off Method V/H Sync+ Blank
Video Off In Suspend Yes
Suspend Type Stop Grant
Modem Use 3
Suspend Mode Disabled
HDD Power Down Disabled
Soft-Off by PWR-BTTN Instant-Off
CPU THRM-Throttling 50.0%
Wake-Up by PCI Card Disabled
Power On by Ring Disabled
Resume by Alarm Disabled
X Date (of Month) Alarm 0
X Time (hh:mm:ss) Alarm 0:0:0
**Reload Global Timer Events**
Primary IDE 0 Enabled
Integrated Peripherals (Continued)
