Mindray Resona R9 Service Manual

9-96 Structure and Assembly/Disassembly
2. Unscrew M6 X 20 (*5) round inner head screws (with pads) with the M6 screwdriver to remove
the bottom cover.
9.3.39.4 Casters
1. Use the spanner (equipped in FRU) to remove the five casters respectively.
Note:
In case of the trolley falling, please uninstall the caster one after one. Do not uninstall
the casters in one time.
Bottom cover (FRU)
Shield cover
Trolley bottom view
