Quick Reference Guide

P/N: 0002-08-50038-00 Rev A

Panorama® Central Station interface: Changing alarm responses at the

Panorama Central Station or WorkStation will not change alarm responses on

the V12 or V21 bedside monitor. Changing alarm responses at the V12 or V21

bedside monitor will not change alarm responses on the Panorama Central

Station and WorkStation.

Adjust Arrhythmia Alarms

To adjust a patient’s arrhythmia alarm on the V12 or V21 bedside monitor:

a. Select ECG waveform to enter ECG Setup tab

b. Select Arrhythmia tab

c. Select individual arrhythmia

d. Select

• On/Off: to enable or disable arrhythmia alarm notification

(A in the box indicates selected)

• High (Red), Medium (Yellow), or Low (Blue) – to adjust the audio and

visual alarm indicators

e. Select Accept to save settings and return to the main screen

a. Select Alarms tab from Navigation Area

b. Select Arrhythmia to enter the Arrhythmia tab
