Minelab Excalibur II User Manual

36 37
No sound
• Check that the detector is on. Try turning both
the Threshold and Volume controls to maximum.
• Check that the battery pack and power cable
are connected securely.
• Check that the battery is charged.
•Try using a different battery pack, available from
your Minelab dealer.
•Check for breaks, cracks or extreme kinks in the
cable assemblies.
Erratic Noises
•Reduce the Sensitivity by turning the control clockwise.
•Check that the battery is properly connected and
fully charged.
•Switch Sensitivity to the Auto position.
•Check for sand or grit between the skid plate and coil.
•Check for overhead power lines and other sources
of electrical interference.
•Check that the controls turn to the correct limits
(marked on the decal). Also check that the ‘clicks’
are present on the Threshold, Disc, Pinpoint/All Metals
and Sensitivity controls.
Troubleshooting Technical
Specifications
Transmission 1.5, 3, 4.5, 6, 7.5, 9 ... 25.5 kHz
Technology BBS - Broad Band Spectrum Technology
Multiple Simultaneous Frequency
Coil (Standard) 8” or 10” Round Double D
Audio Output Koss Headphones supplied - Impedance 8Ω
Length with standard shaft Extended - 1220 mm (48")
Retracted - 1140 mm (45")
Length with diving shaft Extended - 910 mm (36")
Retracted - 820 mm (32")
Weight (including NiMH battery) Including 8" Coil - 2.1 kg (4.6 lbs)
Including 10" Coil - 2.3 kg (5.1 lbs)
Type NiMH Battery Pack 1000 mAh
(Alkaline optional)
Output Voltage 13V when fully charged
Max discharge current is 1A
Capacity when fully charged 14 - 19 hours
Weight 0.3 kg (0.67lbs)
Operating temperature range 0°Cto45°C(32°Fto113°F)
Storage temperature range -20°Cto40°C(-4°Fto104°F)
Battery charge temperature range: 0°Cto45°C(32°Fto113°F)
Battery
Detector
